Specification
| For Contactor | Setting Range (A) | Type | Order Code | |
|---|---|---|---|---|
| Minimum | Maximum | |||
| B6, BC6, VB6, VBC6, B7, BC7, VB7, VBC7 | 0.10 0.13 0.17 0.23 | 0.13 0.17 0.23 0.31 | T16-0.13 T16-0.17 T16-0.23 T16-0.31 | 1SAZ711201R1005 1SAZ711201R1008 1SAZ711201R1009 1SAZ711201R1013 |
| 0.31 0.41 0.55 0.74 | 0.41 0.55 0.74 1.00 | T16-0.41 T16-0.55 T16-0.74 T16-1.0 | 1SAZ711201R1014 1SAZ711201R1017 1SAZ711201R1021 1SAZ711201R1023 |
|
| 1.00 1.30 1.70 2.30 | 1.30 1.70 2.30 3.10 | T16-1.3 T16-1.7 T16-2.3 T16-3.1 | 1SAZ711201R1025 1SAZ711201R1028 1SAZ711201R1031 1SAZ711201R1033 |
|
| 3.10 4.20 5.70 7.60 | 4.20 5.70 7.60 10.0 | T16-4.2 T16-5.7 T16-7.6 T16-10.0 | 1SAZ711201R1035 1SAZ711201R1038 1SAZ711201R1040 1SAZ711201R1043 |
|
| 10.0 13.0 | 13.0 16.0 | T16-13.0 T16-16.0 | 1SAZ711201R1045 1SAZ711201R1047 |
|
